PVC Pipe Threading Machines

PVC Pipe Threading Machines
PVC Pipe Threading Machines
Product Code : 07
Product Description

The PVC Pipe Threading Machines selection we offer is praised by many clients because of durability, precise engineering and optimum output. These machines are employed for cutting the external threads using Tangential chaser that performs as a cutter in the machines. Threads like BSPT, NPT, METRIC, UNC, UNF, BSW, BSP, ACME, BSF Threads, etc., can be cut with these PVC Pipe Threading Machines.

Following major parts form a part of these machines:
  • Base
  • Bed or Pillar Type Clamping Vice
  • Die Head
  • Head Stock
  • Saddle

DESIGN & WORKMANSHIP: These machines can cut, shape and produce quality threads with good tolerance

HEAD STOCK: This provides adequate support to the spindle bearings. The head box is of gear type, and comes equipped with three extra sturdy bearings.

THE BED: In the pillar type Threading Machines, the bed has two SS pillars that are nicely polished and duly hard chrome plated.

THE SADDLE: The Saddle sits on the steel pillars and operates accurately along with the Head Stock alignment.

THE APRON: The apron is responsible for moving the saddle via well designed steel rack and pinion arrangements. Only best quality steel gears are used.

VICE JAWS: The vice jaws fitted on the saddle are designed using best quality alloy steel. The jaws are also heat treated and how they move is controlled by a screw on the saddle.

PVC Pipe Threading Machines and Die Heads We Offer:

  • 1/4″ to 1″ do/-
  • 3/8″ to 1.1/2″ do/-
  • 1/2″ to 2.1/2″ do/-

PVC Pipe Threading Machine

Model

1/4″ to 1″
(Bed Type)

3/8″ to 1.1/2″
(Bed Type)

1/2″ to 2.1/2″
(Pillar Type)(Bed type)

Saddle Movement

10″

10″ – 12″

12″ – 16″

Spindle Speed Range

60-90

60-90

60-90-120

Number of Spindle Speed

2

2

2 or 3

Threading Capacity

1/4″ to 1″

3/8″ to 1.1/2″

1/2″ to 2.1/2″

Production per Hour

60-80

60-80

70-90

H.P. Required

3 H.P.

3 H.P.

7.5 H.P.

Lead Screw

Provided

Provided

Provided

Weight (KG) Aprox.

500

550

990
