Rod Threading Machines

Rod Threading Machines
Rod Threading Machines
Product Code : 09
Product Description

With firm commitment and sincere dedication, we strive to manufacture, supply and export fully functional Rod Threading Machine. The tangential chaser featured in this machine is used for cutting various external threads like ACME, BSPT, UNF, NPT, UNC and metric. In the designing process, our machine is configured with fully operational base, headstock, saddle, bed clamping vice and die head worth different sizes. Offered Rod Threading Machine is known for hassle-free operations, optimum performance and extended service life.

Other details:

Rod Threading Machine is use to cut the external threads with the help of Tangential chaser. Chaser is use as a cutter in Machine. The Component remain still, Die-head rotates and different type of threads can be cut such as BSPT, BSW, BSP, NPT, UNF, METRIC, UNC, ACME, BSF Threads.

It mainly consists the following

  • Base
  • Head Stock
  • Saddle
  • Bed Clamping Vice
  • Die Head.

ROD THREADING MACHINES are designed to give maximum efficiency and reliable performance under the most severe conditions of service with minimum maintenance cost. All the necessary requirements are combined in this model to from the basic fundamentals of correct thread. All the gears are made of case hardened steel with extra large face with and tooth thickness and cut on hobbing machiness for noiseless operation even at high speed. Naturally the are built with high standards of workmanship, material and quality so closely associated with COMPANY TRADITION.

Other details:

Range of IMC Die Heads.

  • 1/4" to 1"
  • 3/8" to 1.1/2"
  • 1/2" to 2.1/2"

Technical Specifications

Model

1/4" to 1" (Bed Type)

3/8" to 1.1/2" (Bed Type)

1/2" to 2.1/2"  (Bed type)

Saddle Movement

10"

10" - 12"

12" - 16"

Spindle Speed Range

60-90

60-90

60-90-120

Number of Spindle Speed

2

2

3

Rod Threading Capacity

1/4" to 1"

3/8" to 1.1/2"

1/2" to 2.1/2"

Production per Hour

60-80

60-80

70-90

H.P. Required

3 H.P.

3 H.P.

7.5 H.P.

Lead Screw

Optional

Optional

Optional

Weight (KG) Aprox.

500

550

990
