Hydraulic Thread Rolling Machine 3 Roll Type
Product Details:
X
Product Description
Hydraulic Thread Rolling Machine 3 Roll Type
IMC Hydraulic Thread rolling machines are used to produce high quality screws and other small tools and components. They are ideal for high volume production, are highly economical and ensure excellent dimensional accuracy. Industrial Machinery Corporation is a well known manufacturer, supplier and exporter of Hydraulic Thread Rolling Machines-Two Roll Types, Hydraulic Thread Rolling Machines-Three Roll Types, etc. These machines are ideal for mass production purposes and help in creating the best surface finishes.
The 3 rollers HU-3R rolling machine operates hydraulically. The simultaneously and concentricity of three forces at 120 assure stability of the work piece during the rolling and as a consequence the maximum geometrical precision of the work piece. The elimination of the support blade consents a better finishing of the piece and the execution of particularly delicate profiles. The machines is suitable for rolling pipes, lapping work, threading with a high class precision and for mass production of Scaffolding pipe jack and solid jacks screws etc.
The maximum values specified above can not be achieved simultaneously.
Specifications:
| Model | IMC-3R-25 | IMC-3R-50 | IMC-3R-75 | |
| Work Range | Out Side Diameter Thread Length in Feed Thread Length Through Feed | (8-25 MM) (1/2"- 1") (38 MM) (1.1/2") (Indefinite) (Indefinite) | (25-50 MM) (1"- 2") (50 MM) (2") (Indefinite) (Indefinite) | (32-75 MM) (1.1/4"- 3") (75 MM) (3") (Indefinite) (Indefinite) |
| Roll Dies | Max. Out Side Dia. Max. Inside Dia Spindle Box | 140 60 40 | 140 60 40 | 170 80 54 |
| Motor | For Roll Spindle | 3 H.P. | 3 H.P. | 7.5 H.P. |
| 3 Phase AC | For Hydraulic System | 1 H.P. | 1 H.P. | 3 H.P. |
| Coolant Pump | | 0.1 H.P. | 0.1 H.P. | 0.1 H.P. |
