Product Description

Hydraulic Thread Rolling Machine 2 Roll Type

We offer well designed Hydraulic Thread Rolling Machine (2 Roll Type) in India and abroad. The Hydraulic Thread Rolling Machine (2 Roll Type) is based on thread rolling, which is a cold-forming operation for external screws threads in a blank. The blank is pressed by thread rolling dies that are attached to the machine. The thread rolling are formed by the pressing progress. The company is counted among the trusted Hydraulic Thread Rolling Machine (2 Roll Type) Manufacturers, suppliers, and Exporters. We offer Hydraulic Thread Rolling Machine (2 Roll Type) at reasonable prices.

Our Thread Rolling Dies are use for threading the component. Rolling dies are made of D2 Material. Thread Rolls are made of imported material.

Used For Manufacturing

Screws
Bolts
Tools

Specifications of Hydraulic Thread Rolling Machine

Model	IMC-25	IMC-40	IMC-50	IMC-80	IMC-100	IMC-120
Max. Pitch Can be Rolling (in mm)	2.5	3.5	4.0	5.0	5.5	8
Max. Dia can be Rolling in feed (in mm)	25	40	50	80	100	125
Max. Dia can be Rolling Through feed (in mm)	16	28	35	40	50	70
Max. Rolling Length in feed (in mm)	80	150	150	150	150	150
Max. Rolling Length Through feed	Indefinite	Indefinite	Indefinite	Indefinite	Indefinite	Indefinite
Max. Outer Dia Thread Rolling Rolls (in mm)	150	180	200	220	220	220
Spindle Dia (Bore Dia) (in mm)	54	54	69.85	69.85	69.85	69.85
Max. Rolling Force	8 Tons	13 Tons	15 Tons	24 TONS	30 Tons	40 Tons
Power for Rolling Spindles	3 H.P. 1400 RPM	5 H.P. 1400 RPM	7.5 H.P. 1400 RPM	10 H.P. 1400 RPM	12. 5 H.P. 1400 RPM	15 H.P. 1400 RPM
Power for Hydraulic Pump	2 H.P.	3 H.P.	5 H.P.	5 H.P.	5 H.P.	7.5 H.P.
Power for coolant pump	0.1 H.P.	0.1 H.P	0.1 H.P	0.1 H.P	0.1 H.P	0.1 H.P.

Other Products in 'Thread Rolling Machines' category

Hydraulic Thread Rolling Machine 3 Roll Type
