Product Description

Bolt Threading Machine

With our consistent efforts, we have placed ourselves as a prominent manufacturer and exporter of Bolt Threading Machine. Threading machine offered by us is widely acclaimed by our precious patrons for its attributes such as energy efficiency, durable performance and corrosion resistance. We use optimum quality raw materials and advanced technologies in manufacturing these machines as per the set industrial quality standards. Bolt Threading Machine offered by us is widely used in industries for cutting external threads of bolt.

Further Details:

The Bolt Threading Machine consists of Base, Head Stock, Saddle, Bed or Pillar Type Clamping Vice, Die Head, Vice Jaws and Apron.

Suitable For

Matric
BSP
BSPT
NPT
UNF
UNC
BSW
Acme threads
B.S.F. threads

Range of Bolt Threading Die-Head

1/4" to 1" do/- Dia Bolt
3/8" to 1.1/2" do/- Dia Bolt
1/2" to 2.1/2" do/- Dia Bolt
1" to 4" Capacity do/- Dia Bolt

Specifications of

Bolt Threading Machine

Model	1/4" to 1" (Bed Type)	3/8" to 1.1/2" (Bed Type)	1/2" to 2.1/2" (Bed type)	1" to 4" (Pillar Type)
Saddle Movement	10"	10" - 12"	12" - 16"	10" - 12"
Spindle Speed Range	60-90	60-90	60-90-120	40-75-115
Number of Spindle Speed	2	2	3	3
Capacity	1/4" to 1"	3/8" to 1.1/2"	1/2" to 2.1/2"	1" to 4"
Production per Hour	60-80	60-80	70-90	35-40
H.P. Required	3 H.P.	3 H.P.	7.5 H.P.	12.5 H.P. 960
Lead Screw	Optional	Optional	Optional	Provided
Weight (KG) Aprox.	500	550	990	1600

IMC Bolt Threading Tangential Chasers are manufactured from imported HSS M2 material which must pass exacting metallurgical standard. Experienced heat treatment with the automatic imported heat treatment plant and imported Testing equipments, assures that they will perform satisfactorily in service and produce quality threads within the tolerance for which they ware intended.

IMC Bolt Threading Tangential Chaser are interchangeable. If one Pc. Of a Bolt Threading chaser set is damaged is beyond use. Then same No. pc. Of the other bolt threading chaser set lying in stock may be used and there will not be any difference in thread performance and the damaged set can be replaced without the necessity of replacing entire set.
